The I.T.CTM System corrects for taper and achieves wall straightness and
the highest possible cutting speeds, by compensating through CNC the
inclination (up to 2°) and orientation of the high pressure water jet. This
ensures a high quality part at a low cost.
During the I.T.C™ compensation, the Jet is also directed towards the piece
in order to reduce the Tail Delay effect and the acceleration-deceleration
ramp times in the corners, for faster and more economical cutting cycles.
The WaterCad-CamTM Software generates the I.T.CTM Program just by a
The five axis Evolution 3D cutting system operates
automatically by maintaining a constant distance
from the nozzle to the material, even during
rotation and interpolation up to ± 69° (optional
90°). This is also possible by a 3D program to
interpolate all the axes simultaneously.
The quarryjet™ technology permits to cut the quarry by an high pressure water jet system (4.130 bar - 60.000 psi) that ejected through a gauged orifice at three times the speed of sound, can realize by a patent device 6 cm. (2,4") Width cut by 7 mt (23') horizontal and vertical depth: the system is developed also to work inside galleries up to 5 mt (17') height able to remove the stone materials by blocks to be used for other purposes.
